Event backdrops you can make! Yes, that’s right! I have the recipe for the pop up walls you’ve been saving on instagram. It folds in half with a hinge, fits in most cars and is lightweight for 1 to carry! Let's get to building.
This makes 1 wall.
If you want to make a shape, slant, or curve thats on you.
How you decorate your walls is endless.
Add pegs, shelves, vinyl, paint, material, etc.
Materials:
11/32 in. or 3/8 in. x 4 ft. x 8 ft. BC Sanded Pine Plywood
11/32 in. or 3/8 in. x 2 ft. x 4 ft.
1 in. x 3 in. x 8 ft.
1 in. x 5 in. x 8 ft.
1 in. x 1 in. x 36 in. Pine Square Dowel
3-1/2 in. Satin Nickel 5/8 in. Radius Smooth Action Door Hinges (Five)
Wood Glue
¾- 1 ¾ wood screws
Sandbag
Sand
Directions:
Cut 4x8 into two 4x3
These are your walls- top + bottom
Cut 11/32 in. or 3/8 in. x 2 ft. x 4 ft. into
Two 1’6” x 2’6” triangles for legs
2-3 inches from the base of the triangle notch out a slit for the leg connector
One 3’ 2.5” x 3” for sandbag leg connector
Two 6” x 6” squares for slat holder
Cut 1 in. x 3 in. x 8 ft. into 4” strips Need 6
One on top half of cut boards, one on bottom half of cut (left, right and center)
Mark and Pre drill your door hinges make sure your screws go through your wood but not the wall, if it does you will have to grind down. Repeat three times.
Cut 1x1 into four 6” and two 4” for the slat holders
Glue them in a u shape on top of the the 6”x6” cuts Need 2
Pre drill and screw center of your hinges on the bottom half right at the fold
Cut 1 in. x 5 in. x 4 ft. into 1.5 foot flats (sand these down for tight fit)
Align your legs at the bottom of the wall half
Mark and Pre drill your door hinges to make sure your screws go through your wood but not the wall, if it does you will have to grind down. Repeat other leg.
Fill sand bag will sand and place on center of 3’ 2.5” x 3” for weighted balance.
Thank you to The Know Women for Giving me the creative space to make thesee beauties.
Thank you to my dad for home depot pop talks.
Thank you to my hubby for the CAD work + love.
If you want to catch the vlog to the wall (BONUS: it’s loaded with Atlas cuteness) it’s here:
